The Fire Water Monitor adopts thermal imaging technology incorporating computerized control, mechanical operation, and remote communication technologies, all built into one unit.
When a fire occurs in the area protected by the Fire Water Monitor, the infrared imaging sensor will detect the flame and activate the device. Water will then be discharged from the nozzle, in the form of a water jet, onto the fire. The device is able to locate the exact position of the fire and direct water discharge at the fire within 30 seconds of its detection of the fire.
InquiryAfter the fire is extinguished, the water discharge can be stopped automatically, then it will automatically return to its standby mode. If the fire re-ignites or there is another fire, the Fire Water Monitor will activate again.
Locate mode: Infrared thermal imaging
sensor + real-time tracking
technology
Detector: Whole plane detection,
large detection range
Basis of positioning: Real-time detecting the
the temperature of each pixel
Working pressure: 0.6MPa
Flow rate: 10L/s
Protection radius: 28m
Jet radius: 32m
Working voltage: 85-242VAC
Power consumption: Locating: max 3 watts
Scanning: max. 10 watts
Positioning time: ≤ the 30s
Fire extinguishing time: ≤3 mins
Horizontal protection angle: 0-360°
Installation height: 6-15m
Scope of application: General purpose industrial buildings and structures, high occupancy places, large space building, for example, airports, railway stations, museums, industrial plants, large shopping malls, large warehouses, power plants, coal mines, colleges, and universities, etc
